TXQ series User’s manual English

TXQ series

The new TXQ is the best solution for those sound reinforcement applications requiring a multichannel amplifier with
a solid and good sounding characteristic but on an affordable budget. Implementing Power Factor Correction (PFC) technology along with Universal Mains Regulated SMPS power supplyand Class D power modules, the TXQ series combines in the same amplifier all the functional requirements for most sound reinforcement applications.

Features

  • Class D power modules.
  • Universal mains Regulated SMPS.
  • XLR signal input and link connectors.
  • SpeakON NL4 and binding-post output connectors.
  • Input sensitivity selector (0.775v / 1v / 32dB).
  • Routing mode selector (stereo / bridge / parallel).
  • Link mode selector (1-in 4-out / 2-in 4-out).
  • Channel independent protection and clip warning indicators on the front panel.
  • Channel independent power and -5dB / -10dB / -20dB / signal presence indicators on the front panel.
  • Lightweight Design.

Applications

  • Sound reinforcement applications with mid power density and good sounding requirements.
  • Small to mid sized bar/café/lounge installation.
  • Portable or rental industry PA system.

Specifications

Model TX 300Q TX 500Q TX 650Q TX 800Q TX1000Q TX 3500Q
Output power (AC 220V/50Hz. +/-10%. All channels driven output power, THD=1%)
8Ω Stereo* 300W x4* 500W x4* 650W x4* 800W x4* 1000W x4* 3500W x4*
4Ω Stereo** 500W x4** 750W x4** 1000W x4** 1300W x4** 1750W x4** 3300W x4**
2Ω Stereo**
8Ω Bridge** 1000W×2** 1500W×2** 2000W×2** 2600W×2** 3500W x2**
Other specifications
Output circuitry Class D
Frequency Response 20Hz-20kHz(+0/-1dB)
THD+N ≤0.1% ≤0.1% ≤0.1% ≤0.1% ≤0.1% ≤0.1%
S/N Rate ≥ 100dB ≥ 100dB ≥ 100dB ≥ 98dB ≥ 98dB ≥ 98dB
Damping factor ≥ 500(1kHz) ≥ 500(1kHz) ≥ 500(1kHz) ≥ 500(1kHz) ≥ 500(1kHz) ≥ 500(1kHz)
Input Sensitivity 0.775v /1.0v/ 32dB 0.775v /1.0v/ 32dB 0.775v /1.0v/ 32dB 0.775v /1.0v/ 32dB 0.775v /1.0v/ 32dB 0.775v /1.0v/ 32dB
Input Impedance (bal/unbal) 20kΩ / 10kΩ 20kΩ / 10kΩ 20kΩ / 10kΩ 20kΩ / 10kΩ 20kΩ / 10kΩ 20kΩ / 10kΩ
Voltage Gain(8 ohm) 36dB 38.2dB 39.3dB 40dB 41.2dB 47dB
Cooling Air flow from front to rear
Dimension / Weight
Product Dimensions (mm) W483 x H306 x D89 W483 x H306 x D89 W483 x H306 x D89 W483 x H306 x D89  W483 x H306 x D89 W483 x H494 x D89
Packing Dimensions (mm) W595 x H565 x D170 W595 x H565 x D170 W595 x H565 x D170 W595 x H565 x D170 W595 x H565 x D170 W620 x H585 x D170
Weight 10.7kg 11kg 11.3kg 12.1kg 12.5kg 15kg

Remark:
1、*,The power is tested under the condition of 40ms burst,1kHz sine wave and 1% THD.
2、**,The other power is tested under the condition of 20ms burst,1kHz sine wave and 1% THD.
3、SAE reserves the right to make any changes to the product specifications without prior notice. Final specifications to be found in the user manual.
